EinScan Medixa 3D Scanner

EinScan Medixa is an all-in-one, wireless 3D scanner built for O&P care—fast, precise, and contact-free. It streamlines clinical workflows while delivering high-quality geometry and texture for confident, patient-friendly outcomes.

Key Features

• All-in-one design — scan, process & export on device
• Wireless, standalone operation — no external PC
• Tailored O&P workflow — intuitive step-by-step UI
• Versatile presets for cranial, face, limbs, torso, foot, socket
• Movement compensation for fidgeting patients & breathing
• High-quality 3D data in STL/OBJ/PLY with minimal post-processing
• 5MP texture capture — detailed, clinician-drawn markings
• Contact-free scanning — clean, comfortable, patient-friendly
• Lightweight & portable for clinic or on-site use
• Easy integration with hospital systems & design portals

	Streamlined Clinical Workflow EinScan Medixa delivers an easy-to-use process that helps clinicians achieve faster results, even without prior 3D scanning experience. Guided step-by-step interface reduces appointment time. Purpose-built for orthotic and prosthetic workflows to improve efficiency. Minimal training required for clinicians and support staff.
Versatile & Personalized Scan Presets EinScan Medixa provides a wide selection of ready-to-use scan presets tailored to suit diverse orthotic and prosthetic applications. Includes preset parameters for cranial, facial, limb, torso, foot, seating, and socket scanning—reducing setup time. Customizable settings allow clinicians to fine-tune parameters for personalized device fabrication.
	Versatile & Personalized Scan Presets EinScan Medixa provides a wide selection of ready-to-use scan presets tailored to suit diverse orthotic and prosthetic applications. Includes preset parameters for cranial, facial, limb, torso, foot, seating, and socket scanning—reducing setup time. Customizable settings allow clinicians to fine-tune parameters for personalized device fabrication.

Specifications

Scan presets: Face, Cranial, Torso, Upper limb, Lower limb, Feet, Socket, Seating, Foam box
Light source: White light | Infrared VCSEL
Point distance: 0.2 ~ 3 mm
FOV: White light: 475 × 360 mm | Infrared VCSEL: 1090 × 1260 mm
Texture camera resolution: 5 MP
Alignment modes: Feature / Texture / Hybrid / Markers / Global markers
